Kent Fire Curtain undergoing testing to BS EN 1634-1

Kent Fire Curtains are life safety systems that are designed to arrest the spread of fire in a building. The assembly comprises a fire resistant fiberglass fabric wound over a roller and all encased in a compact head box that is typically installed above the ceiling to be virtually invisible until activated.

Small scale testing of the Kent Fire Curtain for oversize assessment

When activated by either a general fire alarm or a local detector, the fire curtain descends from its holding position within the head box to its operational position (floor level) and thus forms a physical barrier for fire compartmentalization. Using the Kent Gravity Fail Safe System, our fire curtains descend without the need for power and are fail to safe systems. These fire curtains have enabled large open building designs where otherwise permanent fire rated partitions would be required.

FEATURES

  • Certified to BS EN 1634 Parts 1 and 3
  • E180 and E240 minute fire rated models
  • Compact ‘nearly invisible’ headbox with multiple fixing methods
  • Flexible and durable fire rated fiberglass fabrics
  • Lightweight assembly that greatly lessens structural load
  • Slim compact guides
  • Bottom bar, side guides and headbox can be powdercoated to blend in to surroundings
  • Up to 8.5m width x 7m drop on a single roller
  • Virtually unlimited width without intermediate support using mutliple rollers
  • Kent Guaranteed Gravity Fail Safe (no power needed)
  • Intelligent controls

COMPLIANCE

  • BS EN 1634-1:2014 (fire resistance)
  • BS EN 1634-3:2014 (smoke control test)
  • Fabrics tested to BS 476 Pt 6 and Pt 7, EN 13501-1
  • Fire Curtains tested to UL 10D

FIRE RESISTANCE (E)

  • E180 / E240

RADIATION PERFORMANCE (W)

  • 60 minutes < 15kW/m2

CONSTRUCTION

MULTIPLE ROLLER ASSEMBLY

To achieve a virtually unlimited width without the need for intermediate guide rails, multiple rollers are arranged in an ‘over-under’ (as illustrated) or side by side arrangement and neatly encased within the headbox.

SINGLE ROLLER ASSEMBLY

Smaller widths can be spanned by a single roller curtain

  1. HEADBOX
    The steel headbox houses the roller, fabric and motor within the casing creating a small compact package that remains virtually invisible above the ceiling.

  2. ROLLER AND TUBULAR MOTOR
    A tubular motor drives a steel roller tube to retract and deploy the fabric from normal position in the headbox to its operational position.

  3. GUIDE RAIL
    During deployment, slim steel side guides prevent derailment of the fabric during operation ensuring integrity of the system when faced by positive or negative pressures of a real fire.

  4. FABRIC CURTAIN
    Woven fiberglass wire reinforced fabric with individual panels stitched and hemmed using stainless steel thread.

  5. STEEL BOTTOM BAR
    The Kent profile bottom bar provides weight and stability to the system ensuring a gravity fail safe deployment.

  6. OVER-UNDER ROLLER ARRANGEMENT
    An over-under or side by side arrangement of the barrels (to suit the project requirements) allows multiple rollers to be enclosed in a single compact headbox.

  7. FABRIC OVERLAP
    Multiple rollers utilize the use of a 500mm overlap arrangement which removes the need for intermediate side guides and minimizes the potential for roller bounce.

  8. CONJOINED BOTTOM BAR
    A conjoined bottom bar runs the entire width of the curtain.

HEADBOX FIXING

All fixings.png

HEADBOX ARRANGEMENTS AND CEILING INTERFACE

BOTTOM BAR

Our bottom bar profile is designed to provide the necessary weight to draw the curtain down during a gravity safe deployment and to stablize the curtain during descent. Rolled from galvanized steel, we can powdercoat the bottom bar to match the color of the ceiling.

SIDE GUIDE

Our fire curtain steel side guides can be powdercoated to blend in with the surround wall. In a real fire, these guides help the curtains withstand positive and negative pressures. The stitched fabric inserted into the guide rail is provided with retainer tabs for added strength.

Side Guide Fixing.png
